Home››Thermal Switches››PlugStat (0F-650F)
PlugStat Thermal Switches

PlugStat (0F-650F)

Contact movement is achieved via the different expansion rates of two metals fused together. This is a slow-make-and-break device, which provides very close tolerance temperature sensing, with a small differential.

Set point range: 0°F-650°F (-17.8°C-343°C)

View our RTCA DO-160C Environmental Qualifications Summary

plugstat cutaway thumbnail

Click to Enlarge

View options by configuration:

  • M1 Series – Solder Terminals
  • M2 Series – Glass-sealed Connectors
  • S2 Series – Dual-Setpoint
  • L Series – Ground-to-Case

  • M1 Thermal Switch

    M1001 – Bimetal Thermal Switch, Close-on-Rise, 1/2-20UNF-3A thread

  • M1 Thermal Switch

    M1002 – Bimetal Thermal Switch, Close-on-Fall, 1/2-20UNF-3A thread

  • M1 Thermal Switch

    M1101 – Bimetal Thermal Switch, Open-on-Fall, 1/2-20UNF-3A thread

  • M1 Thermal Switch

    M1102 – Bimetal Thermal Switch, Open-on-Rise, 1/2-20UNF-3A thread

  • CPI Thermal Switches for Aircraft and Avionics

    M2001 – Bimetal Thermal Switch, Close-on-Rise, 1/2-20UNF-3A thread / Glass-Sealed Connector

  • M2002 – Bimetal Thermal Switch, Close-on-Fall, 1/2-20UNF-3A thread / Glass-Sealed Connector

  • M2101 – Bimetal Thermal Switch, Open-on-Fall, 1/2-20UNF-3A thread / Glass-Sealed Connector

  • M2102 – Bimetal Thermal Switch, Open-on-Rise, 1/2-20UNF-3A thread / Glass-Sealed Connector
